tungsten plate manufacturer
Application：
(1)Tungsten plate is used in high temperature furnaces.
(2)Tungsten plate is used in sputtering targets.
(3)Tungsten plate is used in heating elements.
Product Introduction
1. Product name：tungsten plate
Tungsten has the highest melting point of these refractory metals. It is very robust and has an extremely high tensile strength; it has the ability to be drawn into plate. Tungsten’s corrosion resistance is also very good. Due to their thermal properties, high-temperature strength, and excellent creep and corrosion resistance, tungsten plate is used in aerospace. Baoji Magotan Nonferrous Metals is a supplier of high-performance sheet, plate, and ribbon based on precision refractory metals and their alloys.Tungsten plate is used in high temperature industrial applications such as lighting industry, high temperature furnaces, sputtering targets, heating elements, electrodes etc.
2. Specification:
Item name | Grade | Purity | Color | Density | Surface | Size | shape | MOQ |
Tungsten sheet | W1 | 99.95% | silver gray | 19.3g/cm3 | polishing | customer's requirement | square | customer's need |
Tungsten sheet | W2 | 99.95% | silver gray | 19.3g/cm3 | polishing | customer's requirement | square | customer's need |
3. Product grade, Manufacturing Method, Condition and Specification
| Grade | Manufacturing method | condition | Specification/mm | ||
| thickness | width | length | |||
| W1 | baked rolled---relieving stress | Rolling (M) | 0.10-0.20 | 30-300 | 50-1000 |
| >0.20-1.0 | 50-500 | 50-1000 | |||
| hot rolled---relieving stress | >1.0-4.0 | 50-610 | 50-1000 | ||
| >4.0-6.0 | 50-610 | 50-800 | |||
| >6.0-20.0 | 50-610 | 50-800 | |||
| Hot rolled-relieving stress-Machined | Machined(J) | >1.5-20 | 10-300 | 10-610 | |
| Note: After negotiation between the supplier and the buyer, other specifications of tungsten plate can be supplied | |||||
4. Production process flow
5. Application：
(1) Tungsten plate is used in high temperature furnaces.
(2) Tungsten plate is used in sputtering targets.
(3) Tungsten plate is used in heating elements.
6. After-sales instructions
（1）Delivery packaging (The default packaging is thickened carton + shock-resistant bubble film to wrap the goods to ensure that your goods will not be damaged during transportation.
（2）There are special requirements from 20KG, and wooden box packaging can be provided).
（3）Shipping method (express delivery).
（4）Payment for goods (offline payment, payment is transferred to the company account).
（5）Return policy (goods with quality problems or parameter problems can be returned and replaced).
7. Our Company and Factory
We currently work with molybdenum, tantalum, tungsten, zirconium, niobium, titanium and have a deep understanding of the properties and features of each. These metals can be supplied as standard metal parts such as sheets, plates, rods etc. We’re not just metal suppliers. Over the years, our craftsmen have honed their skills on all kinds of projects and are now incredibly talented metal fabricators. in a word, our fabrication workshop is continuously updated with the latest equipment. Meanwhile, we’re able to offer a diverse range of specialist metal fabrication techniques.
