Zirconium 702 Rod

Zirconium and its alloys have good plasticity during cold working, and the cold working performance is similar to low carbon steel, but it is difficult to lubricate and easy to stick to the mold. Surface phosphating or oxidation treatment should be performed on the drawn billet. In order to obtain the desired surface quality, the pipes are generally produced by cold rolling without drawing.

Send Inquiry

Product Introduction

1. Product name: Zirconium 702 rod(UNS R60702)

Zirconium is an important nuclear material because of its excellent nuclear properties and corrosion resistance. Pure zirconium 702 rods are mainly used to manufacture chemical equipment because they are expensive and not much used.

2. Specification of zirconium 702 rod

Grade	Zr 702(UNS R60702)
Purity	99.6%
Density	6.5g/cm3
Melting point	1800℃
Color	Silver
Diameter tolerance	±0.5mm
Shape	Multiple sizes, customized products

3. Description of zirconium 702 rod

(1) Zirconium has a strong affinity with gas. It reacts with oxygen, hydrogen, and nitrogen at about 200, 300, and 400 °C, respectively. The reaction is rapid at higher temperatures, so casting and heat treatment must proceed in a vacuum furnace. Should take appropriate protective measures to shorten the high-temperature working time when thermal processing proceeds in the atmosphere.

(2) The friction coefficient between the zirconium 702 rod and the mold is high, and it is easy to adhere to the surface of the mold.

(3) The processing specification has a more sensitive influence on the performance of the zirconium 702 rod. Should pay special attention to controlling the cold working and heat treatment process before the finished product.

(4) The dimensional accuracy and surface quality of the zirconium 702 rod are very high. Zirconium 702 rod by Magotan, Magotan's process equipment has high precision, and the design and production of tooling and molds are advanced and reasonable.

4. Our company and factory

Magotan specialied in zirconium 702 rod. Magotan has advanced production equipment and testing equipment, mainly engaged in metal processing such as tungsten, molybdenum, tantalum, and zirconium, and the processed products are sold at home and abroad.
